Danfoss VLT AutomationDrive FC 300 Series Service Guide

Block Diagram Name
Spare Part Number
Spare Part Name Comments 200–240 V AC
D1h/D3h D2h/D4h
FC 102 (T2) N55K N75K N90K N100 N150 N160 FC 202 (T2) N55K N75K N90K N100 N150 N160 FC 302 (T2) N45K N55K N75K N90K N100 N150
176F3360 Busbar mains, fuse, RFI D1h/D3h busbars 1 1 1 – – –
176F3368 Busbar motor terminals U,V,W D2h/D4h busbars – – – 1 1 1 176F3371 Busbar mains, no fuse,no RFI D2h/D4h busbars – – – 1 1 1 176F3372 Busbar mains,fuse,no RFI D2h/D4h busbars – – – 1 1 1 176F3373 Busbar mains,RFI,no fuse D2h/D4h busbars – – – 1 1 1 176F3374 Busbar mains,fuse,RFI D2h/D4h busbars – – – 1 1 1 176F3376 Busbar SCR AC input small D2h/D4h busbars – – – 3 3 – 176F3377 Busbar SCR AC input large D2h/D4h busbars - See P/N 185 – – – – 3 3 176F3378 Busbar SCR DC output small D2h/D4h busbars – – – 2 2 –
176F3379 Busbar SCR DC output large D2h/D4h busbars - See P/N 185 – – – – 2 2
176F3380 Busbar DC+ SCR to DC coil D2h/D4h busbars – – – 1 1 1 176F3381 Busbar DC- SCR to DC coil D2h/D4h busbars – – – 1 1 1 176F3382 Busbar DC+ inductor to cap bank D2h/D4h busbars – – – 1 1 1 176F3383 Busbar DC- inductor to cap bank D2h/D4h busbars – – – 1 1 1
176F3384 Busbar IGBT AC output D2h/D4h busbars – – – 3 3 3
176F3385 Busbar assembly current sensor D2h/D4h busbars – – – 1 1 1
176F3386 Busbar assembly cap bank 400V D2h/D4h busbars – – – 1 1 1
Other Parts 176F3353 Door fan lter DH frame package of 10 fan lter 21/54 21/54 21/54 21/54 21/54 21/54
176F3342 Air bae D2h frame enclosure – – – 21/54 21/54 21/54 176F3343 Air bae D4h frame enclosure – – – IP20 IP20 IP20
176F3345 Cable cable 45MM DH frame enclosure 4 4 4 – – –
176F3351 Air bae D3h frame enclosure IP20 IP20 IP20 – – –
176F3352 Air bae D1h frame enclosure 21/54 21/54 21/54 – – –
176F3375 Door vent kit IP21/IP54 DH frame enclosure 21/54 21/54 21/54 21/54 21/54 21/54 176F3389 Front cover IP20 D4h encl enclosure – – – IP20 IP20 IP20
176F3390 Front cover IP20 D3h encl enclosure IP20 IP20 IP20 – – –
176F3479 Power terminal cover IP20 D3h encl enclosure IP20 IP20 IP20 – – – 176F3480 Power terminal cover IP20 D4h encl enclosure – – – IP20 IP20 IP20 176F3481 Mains shield D1h frame enclosure 21/54 21/54 21/54 – – –
176F3482 Mains shield D2h frame enclosure – – – 21/54 21/54 21/54
176F8430 Cable cable for frame size D & E enclosure – – – 4 4 4
Spare Parts
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
330 Danfoss A/S © 02/2019 All rights reserved. MG94A502
1515
