FC 300 Design Guide
How to Program
Function:
This parameter shows the setting of parameter
0-11, as set by the different communication
channels. When the number is read out in hex,
as it is in the LCP, each number represents one
channel. Numbers 1-4 represent a setup number,
"F" means factory setting, and "A" means active
setup. The channels are, from right to left, LCP,
FC-bus, USB, HPFB1-5. Example: The number
AAAAAA21h means that the FC bus selected set-up
2 in parameter 0- 11, the LCP selected set-up 1,
and all others uses the active set-up.
" 0-2* LCP D isplay
0-20 Display Line 1.1 Small
None [0]
Profibus Warning Word [953]
Readout Transmit Error Counter [1005]
Readout Receive Error Counter [1006]
Readout Bus Off Counter [1007]
Warning Parameter [1013]
Running Hours [1501]
kWh Counter [1502]
Control Word [1600]
Reference [Unit] [1601]
Reference % [1602]
Status Word [1603]
Main Actual Value [Unit] [1604]
Main Actual Value [Unit] [1605]
Custom Readout [1609]
Power [kW] [1610]
Power [hp] [1611]
Motor voltage [1612]
Frequency [1613]
Motor Current [1614]
Frequency [%] [1615]
Torque [1616]
* Speed [RPM] [1617]
Motor Thermal [1618]
KTY Sensor Temperature [1619]
Motor Angle [1620]
Phase Angle [1621]
DC Link Voltage [1630]
Brake Energy / s [1632]
Brake Energy /2 min [1633]
Heatsink Temp. [1634]
Inverter Thermal [1635]
Inv. Nom. Current [1636]
Inv. Max. Current [1637]
SL Controller State [1638]
Control Card Temp. [1639]
External Reference [1650]
Pulse Reference [1651]
Feedback [Unit] [1652]
Digi Pot Reference [1653]
Digital Input [1660]
Terminal 53 Switch Setting [1661]
Analog Input 53 [1662]
Terminal 54 Switch Setting [1663]
Analog Input 54 [1664]
Analog Output 42 [mA] [1665]
Digital Output [bin] [1666]
Freq. Input #29 [Hz] [1667]
Freq. Input #33 [Hz] [1668]
Pulse Output #27 [Hz] [1669]
Pulse Output #29 [Hz] [1670]
Relay Output [bin] [1671]
Counter A [1672]
Counter B [1673]
Fieldbus CTW 1 [1680]
Fieldbus REF 1 [1682]
Comm. Option Status [1684]
FC Port CTW 1 [1685]
FC Port REF 1 [1686]
Alarm Word [1690]
Alarm Word 2 [1691]
Warning Word [1692]
Warning Word 2 [1693]
Ext. Status Word [1694]
Ext. Status Word 2 [1695]
PCD 1 Write to MCO [3401]
PCD 2 Write to MCO [3402]
PCD 3 Write to MCO [3403]
PCD 4 Write to MCO [3404]
PCD 5 Write to MCO [3405]
PCD 6 Write to MCO [3406]
PCD 7 Write to MCO [3407]
PCD 8 Write to MCO [3408]
PCD 9 Write to MCO [3409]
PCD 10 Write to MCO [3410]
PCD 1 Read to M CO [3421]
PCD 2 Read to M CO [3422]
PCD 3 Read to M CO [3423]
PCD 4 Read to M CO [3424]
PCD 5 Read to M CO [3425]
PCD 6 Read to M CO [3426]
PCD 7 Read to M CO [3427]
PCD 8 Read to M CO [3428]
PCD 9 Read to M CO [3429]
PCD 10 Read to MCO [3430]
Digital Inputs [3440]
Digital Outputs [3441]
Actual Position [3450]
Commanded Position [3451]
Actual Master Position [3452]
Slave Index Position [3453]
Master Index Position [3454]
Curve Position [3455]
Track Error [3456]
Synchronizing Error [3457]
Actual Velocity [3458]
Actual Master Velocity [3459]
Synchronizing Status [3460]
Axis Status [3461]
Program Status [3462]
*
default setting ()display text []value for use in communication via serial communication port
