Partner: Danish Interpretation Systems
Model: CU6005
Device Type: Miscellaneous Processor
FEEDBACK:
Operation_Mode_Auto_Is_Selected
D High to indicate the current operation mode is auto.
Operation_Manual_Manual_Is_Selected
D High to indicate the current operation mode is manual.
Operation_Manual_FIFO_Is_Selected
S High to indicate the current operation mode is FIFO.
Operation_Manual_VOX_Is_Selected A High to indicate the current operation mode is VOX.
Delegate_Mics_Mute_IS_Selected
D High to indicate the delegate microphones are muted.
Delegate_Mics_Activate_Off_IS_Selected
D High to indicate delegate microphone active is off.
Mic_Activate_Is_Selected
D High to indicate currently selected microphone is active.
Mic_Request_Is_Selected
D High to indicate currently selected microphone is in the request que.
Voting_Is_Opened
D High to indicate voting mode is enabled.
Voting_Mode_3Button_Is_Selected
D High to indicate the current voting mode is 3 button.
Voting_Mode_5Button_Is_Selected D High to indicate the current voting mode is 5 button.
Voting_Mode_Secret_Is_Selected
D High to indicate the current voting mode is secret.
Speaker_Volume_Gauge
A Analog value of speaker volume level to be sent to a touch panel gauge.
Line_Out_Volume_Gauge
A Analog value of line out volume level to be sent to a touch panel gauge.
Vote_Yes_Analog
A Decimal value of total yes votes to be sent to a touch panel digital gauge.
Vote_Abstain_Analog
A Decimal value of total abstain votes to be sent to a touch panel digital gauge.
Vote_No_Analog
A Decimal value of total no votes to be sent to a touch panel digital gauge.
Vote_Attendance_Analog
A Decimal value of total attendance to be sent to a touch panel digital gauge.
Max_Speakers_Analog
A Decimal value of max allowed speakers. Range is 1d to 8d.
Device_Is_Online
D High to indicate Module is connected to the CU6005 Processor.
To_Device
S Serial signal to be routed to a 2-way serial com port.
