DARCHE ECLIPSE 270 - Packing Down the Awning; Pack-Down Procedure

E C L I P S E
PACK-DOWN
7
ECLIPSE 270° AWNING
SET-UP & CARE INSTRUCTIONS
PACK-DOWN
• Undo all pegs / guy ropes.
• Fold away legs and stow away
using attached velcro straps.
• Stow 3 x additional legs in canvas
carry bag.
• Release front and rear
tension straps.
• Fold the RHS of awning back 90°
from the awning body ensuring
the top rafters sit directly on top
of the bottom rafters.
• Fold the LHS of awning back 90°
from the awning body ensuring
the top rafters sit directly on top
of the bottom rafters.
• At this point fold the LHS of the
awning toward the awning body
followed by the RHS. Canvas
should drape down in a triangular
shape.
• Roll canvas and secure using
Velcro straps.
• Position PVC bag over awning and
zip up to complete pack down.
DO NOT STOW THE CANVAS
CARRY BAG CONTAINING
THE ADDITIONAL LEGS
INSIDE THE AWNING’S
TRANSIT COVER.
1
2
3
4
6
5
7
