Transmit beam-forming (TxBF)
WPA3
Wi-Fi
2.4 GHz: two built-in omnidirectional antennas, the max. antenna gain is 4
dBi.
5 GHz: two built-in omnidirectional antennas, the max. antenna gain is 6 dBi.
Bluetooth
One integrated vertically polarized omnidirectional antenna, the max.
antenna gain is 5 dBi.
1 x 100/1000Base-T RJ45 Ethernet port with auto-negotiation
1 x 2.5GE SFP port
1 x RJ45 console port (serial console port)
1 x Bluetooth 5.0
1 x multi-color system status LED
AP power-on status
Software initialization status and upgrade status
Uplink service interface status
Wireless user online status
CAPWAP tunnel timeout
Specific AP locating
Three single-color signal strength LEDs:
Whether bridging is enabled
Whether bridging is successful
Wireless signal strength after successful bridging
1 x Reset button
Press the button for shorter than 2 seconds. Then the device restarts.
Press the button for longer than 5 seconds. Then the device restores to
factory settings.
Main unit: 251 mm x 168 mm x 64 mm (9.88 in. x 6.61 in. x 2.52 in.)
Shipping: 405 mm x 232 mm x 325 mm (15.94 in. x 9.13 in. x 12.80 in.)
Main unit: 1.0 kg (2.2 lbs)
Mounting bracket: 0.9 kg (1.98 lbs)
Shipping: 3.15 kg (6.94 lbs)
Wall or Pole-mounting (a mounting bracket is delivered with the main unit)
The AP supports the following two power supply modes:
48 V DC/0.35 A power input over DC connector: The DC connector accepts
the center-positive circular plug with the inner diameter of 2.0 mm (0.08 in.)
or outer diameter of 6.3 mm (0.25 in.) and the length of 9.8 mm (0.39 in.). A
DC power supply needs to be purchased independently.
PoE input over ETH/PoE: The power source equipment (PSE) complies with
IEEE 802.3af/at standard (PoE/PoE+).
Note: If both DC power and PoE are available, DC power is preferred.
