DKM-411 Modbus Application Manual V3.0 (15.01.2017)
- 15 -
Alarm bits. Bit definitions are given at the end of the document.
Warning bits. Bit definitions are given at the end of the
document.
Bit_0: Input_1 warning
Bit_1: Input_2 warning
Relay function bits. Each bit represent the activation status of
the related function. The list of relay function bits is given at the
end of this document.
Bit_0: Input_1 alarm
Bit_1: Input_2 alarm
Phasor diagram: phase angle of voltage V2 (V1 angle = 0)
Phasor diagram: phase angle of voltage V3 (V1 angle = 0)
Phasor diagram: phase angle of voltage I1 (V1 angle = 0)
Phasor diagram: phase angle of voltage I2 (V1 angle = 0)
Phasor diagram: phase angle of voltage I3 (V1 angle = 0)
0: 3 phase, 4 wire star
1: single phase, 2 wire
2: 2 phase, 3 wire L1-L2
3: 3 phase, 3 wire
4: 3 phase, 4 wire delta
5: 3 phase, 3 wire, 2CTs L1-L2
6: 3 phase, 3 wire, 2CTs L1-L3
Device Unique ID, 24 hexadecimal characters
Successful IP packet counter
