86 Appendix E: MIDI Implementation Dave Smith Instruments
*Controller received, but not transmitted.
†Controller transmitted, but ignored when received.
*OREDO3DUDPHWHU'DWD
The table shows the global data sent and received on global parameter
dumps, and corresponding NRPN number when sent/received individually.
NRPN Range Description
4097 0-100 Master Coarse Tune
4096 0-24 Master Fine Tune
4098 0-16 MIDI Channel
0 = All
4099 0-3 MIDI Clock Mode
0 = Off
1 = Master
2 = Slave
3 = Slave Thru
4100 0-1 MIDI Clock Cable
0 = MIDI Port
1 = USB
4101 0-2 MIDI Param Send*
0 = NRPN
1 = CC
2= Off
4102 0-2 MIDI Param Receive†
0 = NRPN
1 = CC
2= Off
4103 0-1 MIDI Control Enable
0 = Off
1 = On
4104 0-1 MIDI SysEx Cable
0 = MIDI
1 = USB
4105 0-3 MIDI Out Select
0 = Off
1 = MIDI
2 = USB
3 = MIDI+USB
4107 0-1 Local Control*
0 = Off
1 = On
4109 0-2 Pot Mode
0 = Relative
1= PassThru
2 = Jump
4111 0-3 6HT3HGDO0RGH
0 = normal
1= trigger
2= gate
3= trigger+gate
NRPN Range Description
4112 0-3
Sustain Polarity
0 = normally open
1= normally closed
2= Sustain Normally Open/
Sequencer Normally Closed
3= Sustain Normally Closed/
Sequencer Normally Open
4113 0-3
Velocity Curve
4114 0-3 Pressure Curve
4115 0-1 Mono/Stereo
Mono/Stereo
0 = Stereo
1 = Mono
4116 0-16 Alt. Tunings
4118 0-1 MIDI Prog Enable
0 = Off
1 = On
4119 0-1 Multi Mode
0 = Off
1 = On
4120 0-1 Screen Saver
0 = Off
1 = On
4121 0-1 Sustain/Arp
4190 0-1 Layer A/B Switch
