90 Appendix E: MIDI Implementation Dave Smith Instruments
Control NRPN Data
The following table lists the Rev2’s control NRPN data. It is received
and transmitted but not saved as part of a program.
NRPN Value Description
1088 0-1 6HT3OD\6WRS
16383 0-1 6HT5HF2Q2II
SysEx Messages
8QLYHUVDO6\VWHP([FOXVLYH0HVVDJH'HYLFH,QTXLU\
Status Description
1111 0000 System Exclusive (SysEx)
0111 1110 Non-realtime message
0vvv vvvv If MIDI channel is set to 1 - 16, 0vvvvvvv must match (unless MIDI Channel = ALL); always
responds if 0vvvvvvv = 0111 1111.
0000 0110 ,QTXLU\0HVVDJH
0000 0001 ,QTXLU\5HTXHVW
1111 0111 End of Exclusive (EOX)
The Rev2 responds with:
Status Description
1111 0000 System Exclusive (SysEx)
0111 1110 Non-realtime message
0vvv vvvv If MIDI Channel = ALL, 0vvvvvvv = 0111 1111. Otherwise 0vvvvvvv = Channel Number
0 - 15.
0000 0110 ,QTXLU\0HVVDJH
0000 0010 ,QTXLU\5HSO\
0000 0001 DSI ID
0010 1111 Rev2 ID (Family LS)
0000 0001 Family MS
0000 0000 Family Member LS
0000 0000 Family Member MS
0jjj nnnn Main Software version: jjj - Minor rev; nnnn - Major rev
1111 0111 End of Exclusive (EOX)
