4. TECHNICAL INFORMATIONS
Model
Power
Dimensions
Weight
(kW)
Y*G*D (mm)
(Kg)
3~400 V 50 Hz Electrical Only Heating Without Pump and
Expansion Tank
UKDAX-60ETP
60
900*600*290
37,8
UKDAX-72ETP
72
900*600*290
37,8
UKDAX-80ETP
80
900*600*290
37,8
UKDAX-96ETP
96
900*600*290
37,8
Technical Informations
Heating (Radiator)
Min. Operation Pressure
bar
1
Max. Operation Pressure
bar
3
Min. Setting Temperature
°C
10
Max.Setting Temperature
°C
80
Connections
İnch
1
