Daymak Boomerbuggy User Manual

25
▓ SPECIFICATION
Remark: The manufacturer reserves the right to modify the specification if necessary. The final
specification is subject to the individual scooter you purchase from your dealer.
Note:
Maximum driving distance is based on an ambient temperature of 20C, a 75kg driver and a brand new
fully charged battery by a constant driving speed at 6.4 km/h with 70% battery power discharged.
7. T RO U B L E S H O O T I N G A N D S P E C I F I C AT I O N
Model Reference
Boomerbuggy – Super Transporter
Expand Dimension (L x W x H mm)
(L x W x H inch )
47.2" ×20" ×38.1"
1200mm×510mm×970mm
Fold Dimension (L x W x H mm)
(L x W x H inch )
20"×18.1"×25.9"
510mm×460mm×660mm
Weight w/i battery
without battery
31 kg / 68.2 lbs
24.5 kg / 53.9 lbs
Battery
10 AH × 2
Controller
DYNAMIC DR50
Front Wheel Size
150×30 Solid
Rear Wheel Size
200×50 Solid
Brake System
Electromagnetic brakes
Control Method
By speed control lever
Max Speed Forward
6.4km/h / 4mph
Cruising range
9 km /14.4 miles（10AH）
Max Loading
115 kg / 253 lbs
drive system
Direct drive the rear wheels
motor specifications
270w × 24V × 1pcs
frame construction type and materials
Aluminum
battery charger type
and input voltage
off-board
Input AC 100-240V, Output DC 24V, 1.5 Amp
suspension
No
safety features
Anti-tip wheel

Daymak Boomerbuggy Specifications

General

Brand	Daymak
Model	Boomerbuggy
Category	Scooter
Language	English
