3
Required Tools and Parts
Tools Required for Installation
Additional Items Required for Installation
• Ratchet, sockets and wrench set
• Wire cutters/crimpers
• Electric drill/screw gun and bits
• Welding equipment (if welding leg or bracket in place)
• Fasteners for mounting jacks to frame, minimum 1/2” diameter grade 5
• # 4 AWG power wire **(to connect battery +12V positive to the pump) *
• # 4 AWG ground wire **(to connect battery -12V ground to pump) *
• # 4 AWG ring terminals **
• Circuit breaker 100 or 150 amp manual reset type. For additional information please see page 14.
• Loom clips (to secure harness and hydraulic hoses to the coach)
• Self-drilling screws or pop rivets or other to secure harness and hoses.
• Wire ties
• 10 – 16 quarts, could be more depending on system, Automatic Transmission Fluid (Dexron or
multi-purpose ATF)
*Note: These items must be # 2 AWG or larger if cable run is greater than 12 ft
Note: Modication of any factory supplied item may result in the denial of all warranty claims.
Call Equalizer Systems Technical Support prior to any modications.
With any hydraulic application, holding position on a cylinder must be done with safety in mind. Failure in
the system may cause the jacks to retract or extend suddenly. When working under or near the coach, always
use jack stands of appropriate rating to support the weight of the coach.
