SPECIFICATIONS
DCM6
Driver Compliment
Woofer- 6-1/2” polypropylene cone with pole mounted phase plug
Tweeter- 1.8kHz constant directivity Horn Loaded
Frequency Response: 58Hz - 20kHz
Impedance: 8 ohms nominal
Power Handling: 75 watts RMS / 150 watts total
Sensitivity: 89dB 1W/1m
Shipping Weight: 17.0 lbs. / 7.7kg
Dimensions: 12.992” H x 7.992” W x 7.795” D
33.0cm H x 20.3cm W x 19.8cm D
DCM6C
Driver Compliment
Woofer- 6-1/2” polypropylene cone with pole mounted phase plug
Passive Radiator- 6-1/2” polypropylene cone with pole mounted phase plug
Tweeter- 1.8kHz constant directivity Horn
Frequency Response: 58Hz - 20kHz
Impedance: 8 ohms nominal
Power Handling: 75 watts RMS /150 watts total
Sensitivity: 91dB 1W/1m
Shipping Weight: 11.0 lbs. / 5.0kg
Dimensions: 7.992” H x 19.685” W x 7.204” D
20.3cm H x 50.0cm W x 18.3cm D
DCM10
Driver Compliment
Woofer- 10” large excursion composite pulp cone
Midrange- 6-1/2” polypropylene cone with pole mounted phase plug
Tweeter- 1.8kHz constant directivity Horn Loaded
Frequency Response: 35Hz - 20kHz
Impedance: 8 ohms nominal
Power Handling: 200 watts RMS / 400 watts total
Sensitivity: 94dB 1W/1m
Shipping Weight 43.0 lbs. / 19.5kg
Dimensions: 31.312” H x 15.825” W x 12.501” D
79.5cm H x 40.2 cm W x 31.8 cm D
DCM12
Driver Compliment
Woofer- 12” large excursion composite pulp cone
Midrange- 6-1/2” polypropylene cone with pole mounted phase plug
Tweeter- 1.8kHz constant directivity Horn Loaded
Frequency Response: 30Hz - 20kHz
Impedance: 8 ohms nominal
Power Handling: 250 watts RMS / 500 watts total
Sensitivity: 97dB 1W/1m
Shipping Weight: 53.0 lbs. / 24.1kg
Dimensions: 33.312” H x 17.638” W x 15.938” D
84.6cm H x 44.8cm W x 40.5cm
should be spaced equal distances from the listening position with the tweeters at
or above ear level.
