DCS RD 486 GD - Page 13

PARTS LIST:
ITEM # PART # DESCRIPTION
1 12112-01 TOP HALF GRATE
2 12131-PC SIMMER TUBE CAP
3 12139 SIMMER BURNER CAP
4 12138 SIMMER BURNER BASE
5 12105-PC AERATION BOWL
6 12093 ELECTRODE ASSEMBLY
7 12094 ELECTRODE SPRING CLIP
8 15001-22 BURNER BASE SCREWS
9 15002-26 VENTURI BOLT
10 14000 VENTURI GASKET
11 12113 MAIN VENTURI, REAR
12 90653-02-PL SIMMER VENTURI, REAR
13 15021-04 VENTURI NUT
14 13236 SPARK MODULE
15 90653-01-PL SIMMER VENTURI, FRONT
16 12114 MAIN VENTURI, FRONT
17 16006 TERMINAL BLOCK
18 15109 VALVE SCREW / PLUG / WASHER
19 16212 POWER CORD - RANGES
20 13071 SPARK SWITCH / SIMMER, STD. BURNER
21 14006-PL BEZEL
22 14125 SIMMER BURNER KNOB
23 14124 SIMMER BLOCK O-RING
24 13070 SIMMER BLOCK
25A 13005-79 SIMMER ORIFICE HOOD, LP GAS
13005-75 SIMMER ORIFICE HOOD, NATURAL GAS
25 13005-58 MAIN ORIFICE HOOD, LP GAS
13005-51 MAIN ORIFICE HOOD, NATURAL GAS
26 13228 MAIN BURNER VALVE
27 90129 BURNER HANGER
28 90085-01 GRATE SUPPORT (3/4” WIDE) (L/R)
29 90084-01 GRATE SUPPORT (1 1/2” WIDE) (CENTER)
30 MANIFOLD ASSEMBLY (Complete w/Valve/Regulator)
90324 DCS-RD-484GG
90324-01 DCS-RD-486GL
90324-02 DCS-RD-486GD
90324-03 DCS-RD-366
90324-05 DCS-RD-364GL
90324-06 DCS-RD-364GD
31 12111 AIR SHUTTER SIMMER
32 13003 REGULATOR
NOTE: Burner Base Assembly Front – 90146-01 (includes item # 2,3,4,6,7,10,11,12)
Burner Base Assembly Rear – 90145-02 (includes item # 2,3,4,6,7,10,11,12,15,16)
12
OPEN TOP BURNER ASSEMBLY
