17
PARTS LIST:
ITEM # PART # DESCRIPTION
1 90253-02 GRIDDLE COVER
2 90582 GRIDDLE FLUE COVER
3 90192-01 GRIDDLE / GRILL FRONT TRIM
4 90192-02 GRIDDLE FRONT TRIM
5 90133 GRIDDLE PLATE ASSEMBLY
6 12005-1 GRIDDLE BURNER
7 16009-1 IGNITER
8 90141 GRIDDLE BAFFLE
9 30313-3 DRIP PAN LINER
10 90045-01 GRIDDLE TUBING (484GG)
90746-04 GRIDDLE TUBING (364GD/484GD)
11 13073 THERMAL VALVE (NAT)
13073-01 THERMAL VALVE (LP)
12 18017 ELBOW ASSEMBLY
13 18166 MANIFOLD ADAPTER
14 18165 PIPE PLUG
15 15109 VALVE SCREW / PLUG / WASHER
16 16046-02 INDICATOR LIGHT
17 13310 GRIDDLE THERMOSTAT
18 14006-PL BEZEL
19 14129 GRIDDLE THERMOSTAT KNOB
20 16077 FIBER GLASS SLEEVE
21 16006 TERMINAL BLOCK
22 13005-48 ORIFICE HOOD-NATURAL GAS (#48 DMS)
13005-55 [ORIFICE PIN-LP GAS (#55 DMS)
(INTEGRAL TO THERMAL VALVE)]
23 18204-01 GRIDDLE COVER HANDLE
15139 GRIDDLE COVER HANDLE SCREW (2)
24 18077-2 FERRULE 3/8
25 18077-1 COMPRESSION NUT 3/8
GRIDDLE ASSEMBLY
