DCS RD 486 GD - Page 22

PARTS LIST:
ITEM # PART # DESCRIPTION
1 90254-02 GRILL COVER W/ PULL HANDLE
2 90192-03 GRILL FRONT TRIM
3 12148 CAST IRON GRATE
4 90262-01 BRIQUETTE TRAY ASSEMBLY
5 12134 GRILL U-BURNER
6 90630 GRILL BOX ASSEMBLY
7 13073 THERMAL VALVE (NAT)
13073-01 THERMAL VALVE (LP)
8 90045-02 GRILL TUBING
9 16009-01 IGNITER
10 18165 PIPE PLUG
11 13005-48 ORIFICE HOOD-NAT. GAS (#48 DMS)
13005-55 ORIFICE HOOD-L.P. GAS (#55 DMS)
(INTEGRAL TO THERMAL VALVE)
12 16001 MICROSWITCH
13 13068 SIMMER VALVE-STANDARD
14 18030 ELBOW
15 15109 BOLT / GASKET
16 90260 CAM - GRILL SWITCH
17 14006-PL BEZEL
18 14130 GRILL KNOB
19 16077 FIBERGLASS SLEEVE
20 16006 TERMINAL BLOCK
21 15112 SPEED CLIP - CAM - GRILL SWITCH
22 18077-2 FERRULE 3/8
23 18077-1 COMPRESSION NUT 3/8
21
GRILL ASSEMBLY
