PARTS LIST:
ITEM # PART # DESCRIPTION
1 90947-01 SLIDE RACK SUPPORT WELD ASS’Y (L/H)
90947-02 SLIDE RACK SUPPORT WELD ASS’Y (R/H)
2 91341 BRACKET MICROSWITCH - INTERLOCK KIT
3 91329 MICROSWITCH - INTERLOCK
3A 91162 PUSH ROD SWITCH - INTERLOCK
4 16028-2 BROIL ELEMENT 4,000 WATT
5 16030-2 BAKE ELEMENT 6,000 WATT
5A 90515 BAKE ELEMENT SUPPORT ASS’Y
6 90649-PC CONVECTION BAFFLE
7 15226 THUMBSCREW - RACK SUPPORT
8 16032-1 5 PUSH-BUTTON SELECTOR SWITCH
9 16212 POWER CORD
10 16046-02 INDICATOR LIGHT
11 16077 FIBERGLASS SLEEVE
12 13037 THERMOSTAT KS-HT
13 14006-PL BEZEL
14 14126-01 KNOB OVEN - SELF CLEAN
15 50135 CAPILLARY BULB SUPPORT
16 90392 - PC 27” OVEN TANK ASSEMBLY
17 13043 HIGH TEMP CUT-OUT
18 16242 OVEN LAMP ASSEMBLY
* 90478 GUIDE CENTER DRIP PAN
* 90237 GUIDE DRIP PAN
21 50231 CONTROL BOX 36”
500036 CONTROL BOX 48”
22 13038 50% PULSER
23 16044-1 12” OVEN TIMER-PROOF
24 16044-2 27” OVEN TIMER-CLEAN
25 13039 12” OVEN HOT WIRE RELAY
26 13039 27” OVEN HOT WIRE RELAY
27 16045-2 FLANGE MOUNT RELAY DPDT
28 16045-2 FLANGE MOUNT RELAY DPDT
29 16045-2 FLANGE MOUNT RELAY DPDT
30 16045-3 FLANGE MOUNT RELAY TPDT
31 16049 TERMINAL BLOCK
32 50166 BLOWER MOTOR
33 16038 AIR INTERLOCK SWITCH
34 16148 WHEEL BLOWER
35 16155 WHEEL COOLING RVCR 8712-100 HS
36 16147 MOTOR - CONVECTION RD
37 16031 MOTORIZED DOOR LOCK
38 12063 CATALYST
39 19048 OVEN RACK LARGE OVEN
40 19003-2 OVEN RACK SMALL OVEN
41 14051-01 BUTTON PUSH
* 14052 OVEN DOOR GASKET
42 90458 LIFT CHANNEL INTERLOCK
*
ITEMS NOT PICTURED
25
27” OVEN PARTLIST
