PARTS LIST:
ITEM # PART # DESCRIPTION
1 90947-01 SLIDE RACK SUPPORT WELD ASS’Y (L/H)
90947-02 SLIDE RACK SUPPORT WELD ASS’Y (R/H)
2 91342 BRACKET MICROSWITCH - INTERLOCK KIT
2A 90525-01 EDGE GUARD (L/H)
90527-02 EDGE GUARD (R/H)
3 91330 MICROSWITCH - W/A INTERLOCK
4 16248 BROIL ELEMENT
5 16158 BAKE ELEMENT
5A 16265 BAKE ELEMENT INNER
6 90750-PC CONVECTION BAFFLE
7 15226 THUMBSCREW - RACK SUPPORT
8 16032-1 5 PUSH-BUTTON SELECTOR SWITCH
9 16212 POWER CORD
10 16046-02 INDICATOR LIGHT
11 13234 T-STAT MAIN OVEN E/R 35
12 14006-PL BEZEL
13 14190 KNOB OVEN - SELF CLEAN
14 13043 HI-TEMP CUT-OUT
15 16242 OVEN LAMP ASSEMBLY
16 50231 ELECTRICAL CONTROL BOX
17 13038 50% PULSER
18 16044-2 OVEN TIMER - CLEAN
19 16045-2 FLANGE MOUNT RELAY DPDT
20 16045-3 FLANGE MOUNT RELAY TPDT
21 16049 TERMINAL BLOCK
22 16327 CONVECTION MOTOR
23 16038 AIR INTERLOCK SWITCH
24 50166-01 BLOWER MOTOR
25 16247 MOTORIZED DOOR LOCK
26 13233 T-STAT E/R 25
* 14052 OVEN DOOR GASKET
27 90802 CLIP OVEN SEAM
28 15003-26 HEX BOLT 1/4-20 X 3.5 SS
29 15029 NUT W/RET. 1/4-20
30 90759-PC OVEN TANK W/A
31 90404-01 BRACKET INTERLOCK UPPER L/H
32 90404-02 BRACKET INTERLOCK UPPER R/H
33 16130 CONVECTION BLADE
34 90171 MOTOR COVER PAD
35 90170 MOTOR INSULATION PAD
36 90285 MOTOR PAD
37 16053 MOTOR COOLING BLADE
38 90276 BRACKET MOTOR
39 90771 BRACKET CHANNEL
40 90789 REFLECTOR
41 19048-01 OVEN RACK RD-304
42 12063 CATALYST
* ITEMS NOT PICTURED
27
RD-304 24” OVEN
