PARTS LIST:
ITEM # PART # DESCRIPTION
1 19004-1 12” OVEN RACK SUPPORT
2 19003-2 12” OVEN RACK
3 50087-1 BRACKET - RACK
4 16029-2 BROIL ELEMENT 3,600 WATTS
5 16027-2 BAKE ELEMENT 3,700 WATTS
6 50011-01-PC OVEN BOTTOM PAN
7 50096 CLIP- OVEN SEAM
8 16032-2 4 PUSH-BUTTON SELECTOR SWITCH
9 16212 POWER CORD
10 16046-02 INDICATOR LIGHT
11 16077 FIBERGLASS SLEEVE
12 13037 THERMOSTAT KS-HT
13 14006-PL BEZEL
14 14126-02 KNOB 12” OVEN
15 50135 CAPILLARY BULB SUPPORT
16 50058-PC 12” OVEN TANK ASSEMBLY
17 13043 HIGH TEMP CUT-OUT
18 16242 OVEN LAMP ASSEMBLY
19 50018-2 REFLECTOR
* 14053 OVEN DOOR GASKET
21 50036 ELECTRICAL CONTROL BOX
22 13038 50% PULSER
23 16044-1 12” OVEN TIMER-PROOF
24 16044-2 27” OVEN TIMER-CLEAN
25 13039 12” OVEN HOT WIRE RELAY
26 13039 27” OVEN HOT WIRE RELAY
27 16045-2 FLANGE MOUNT RELAY DPDT
28 16045-3 FLANGE MOUNT RELAY TPDT
29 16049 TERMINAL BLOCK
30 50166 BLOWER MOTOR
31 16038 AIR INTERLOCK SWITCH
* ITEMS NOT PICTURED
29
12” OVEN
