PARTS LIST:
ITEM #
PART # DESCRIPTION
1 90104-01 RD 48 LANDING LEDGE
90104-02 RD 36 LANDING LEDGE
2 90300-01-PA RD 484GG VALVE PANEL
90300-03-PA RD 486GD VALVE PANEL
90300-02-PA RD 486GL VALVE PANEL
90531-01-PA RD 366 VALVE PANEL
90531-03-PA RD 364GD VALVE PANEL
90531-02-PA RD 364GL VALVE PANEL
3** 90303-01 RD 48 RIGHT BODY PANEL
90469-01 RD 36 RIGHT BODY PANEL
3A *90310-01 RD 48 RIGHT SIDE INSUL. RET.
4** 90303-02 RD 48 LEFT BODY PANEL
90469-02 RD 36 LEFT BODY PANEL
4A *90310-02 RD 48 LEFT SIDE INSUL. RET.
5 18052-2 LEVELING LEG
6** 90323 RD 48 KICK PANEL ASSEMBLY
90551 RD 36 KICK PANEL ASSEMBLY
7 150034-3 HINGE RECEPTACLE
8 90186-01-PC 27" DOOR INSIDE LINER
9 150034-1 27" OVEN DOOR HINGE
10 14131 WINDOW PACK-27
10A 14045 WINDOW GASKET-27
11** 90662-01 27" Oven Door Panel Assy. (w/ Glass/Tape)
11A* ** 90184-05 27” OVEN DOOR ASSEMBLY-Complete
12 17130-01 DCS LOGO -LG-BLACK. (RANGES)
13 90187-02 27" OVEN DOOR HANDLE
14 18164-PL DOOR HANDLE ENDCAP
15A** 90662-06 12" Oven Door Panel Assy. (w/ Glass/Tape)
15** 90184-06 12” OVEN DOOR ASSEMBLY-Complete
16 90187-01 12" DOOR HANDLE
17 91254 27" DOOR INSULATION RETAINER (RD 48/36)
18 90412 12" DOOR INSULATION RETAINER
19 90403-PC 12" DOOR INSIDE PANEL
20 15001-39 BOLT - DOOR HANDLE
21 15002-41 SCREW - DOOR TOP
22 90658-02(L/H)/90658-01(R/H) DRIP PAN - 48"
90658-03 DRIP PAN - 36"
22A 90624(L/H)/90623(R/H) DRIP PAN HANDLE - 48"
90625 DRIP PAN HANDLE - 36”
23 30313-3 DRIP PAN LINER (UNDER GRILL/ GRIDDLE ONLY)
24 150034-2 12" OVEN DOOR HINGE
25 90470-02(R/H), 90470-01(L/H) RD 36 SIDE COVER
26 14138 WINDOW PACK-12” DOOR
27 16127 LIGHT SWITCH - OVEN
28 15002-41 (4) FRONT PANEL SCREWS
* 14052 27” OVEN DOOR GASKET (FRAME)
* 14053 12” OVEN DOOR GASKET (FRAME)
* ITEMS NOT PICTURED
** COLOR OTHER THAN (SS) MUST BE SPECIFIED
6
OUTER BODY PARTS LIST
