PARTS LIST:
ITEM # PART # DESCRIPTION
1 90104-03 LANDING LEDGE
2 90440-PA VALVE PANEL
3** 90432-01 RIGHT BODY PANEL
3A 90431-01 RIGHT SIDE INSUL. RET.
4 90432-02 LEFT BODY PANEL
4A** 90431-02 LEFT SIDE INSUL. RET.
5 18052-2 LEVELING LEG
6** 90758 KICK PANEL ASSEMBLY
7 150034-3 HINGE RECEPTACLE
8 90766-01-PC DOOR INSIDE LINER
9 150034-1 OVEN DOOR HINGE
10 14131 WINDOW PACK
10A 14045 WINDOW GASKET
11** 90765-12 Oven Door Panel Assy. (w/ Glass/Tape)
11A* ** 90765-02 OVEN DOOR ASSEMBLY-Complete
12 17130-01 DCS LOGO -LG-BLACK. (RANGES)
13 90187-03 OVEN DOOR HANDLE
14 90561 DOOR INSULATION RETAINER
15 15001-39 BOLT - DOOR HANDLE
16 15002-41 SCREW - DOOR TOP
17 90772 DRIP PAN ASSEMBLY
18 16127 LIGHT SWITCH-OVEN
19 15002-41 FRONT PANEL SCREWS
20 18164-PL DOOR HANDLE ENDCAP
* 14052 OVEN DOOR GASKET
* ITEMS NOT PICTURED
** COLOR OTHER THAN (SS) MUST BE SPECIFIED
8
RD-304 OUTER BODY PARTS LIST
