24
2 Learning the First Remote Control or Additional Remotes in Motor Control Mode
Phase
Description
Example
1
Press 2 times shortly the programming button of the MINI-RX. The LED on the receiver will per-
form 2 blinks and the buzzer will perform two beep every 2 seconds.
2
Hold down the programming button of the MINI-RX for more than 3 seconds. The LED on the
receiver will perform another blink and the buzzer another acoustic warning.
3
Press the programming button a number of times equal to the output you want to program:
1 pressure -> mode 2.1 - Stepped
2 pressures -> mode 2.2 - Ascent/stop
3 pressures -> mode 2.3 - Descent/ stop
4 pressures -> mode 2.4 – Deadman stepped
5 pressures -> mode 2.5 – Deadman Ascent
6 pressures -> mode 2.6 – Deadman descent
7 pressures -> mode 2.7 - Stop
8 pressures -> mode 2.8 - Ascent
9 pressures -> mode 2.9 - Descent
10 pressures -> roll back mode 2.1
The system will notify the user the selection just made with a number of LED blinks (fast), and
acoustic warnings equal to the selected output, repeated every 2 seconds.
4
Press the button on the remote that you want to store.
After saving the receiver will perform two long blinks of the LED and 2 long beeps of the buzzer.
5 To learn another remote control (or another button), repeat step 3.
6
To complete the learning of a remote control, wait for the programming timeout that will be
indicated by a long beep and a long blink of the LED.
NOTE: if the memory is full or whenever the remote control is already present in the memory,
the receiver will perform 10 blinks and 10 acoustic warnings.
7 End
Notes:
- Maximum timeout in Motor mode: 6 minutes
- Default timeout in Motor mode: 4 minutes
