L I V I
Operatinginstructionsandwarnings
7
LIVI
Electromechanicaloperatorsforslidinggates
Operating instructions and warnings ENGLISH
INDEX
 Declarationbymanifacturer..........................1
 OVERVIEW.......................................................7
1 PRODUCTCONFORMITY..................................7
2 RESIDUALRISKWARNINGS............................7
3 MODELSANDCONTENTSOFTHEPACKAGE...8
4 OPERATINGINSTRUCTIONS...........................8
4.1 Productdescription................................8
4.2 Technicaldata........................................8
4.3 Labellinginformation............................8
4.4 Appropriateconditionsofuse..............8
4.5 Instructionsforrisk-freeoperation........9
4.5.1Transport–9
4.5.2Installation,assembly
 anddisassembly–9
4.5.3Starting–9
4.5.4Use–9
4.5.5Adjustment–9
4.5.6Maintenanceandrepair–9
4.6 Training...............................................10
4.7 Inappropriateuse................................10
5 SPAREPARTSLIST..........................................10
6 COMPLETECLOSINGASSEMBLY...................10
6.1 Minimumlevelofprotection
 providedbythesafetyedge................10
6.2 Crushingintheopeningarea.............10
6.3 Impactintheopening/closingarea....10
 Exampleoftypicalinstallation............27
ANNEXES
- Instructionsforthefinaluser
- Termsofwarranty
OVERVIEW
SCOPEOFTHEINSTRUCTIONS
Theseinstructionswerepreparedbythemanufacturerand
areanintegralpartoftheproduct.Theoperationsdescribed
areintendedforadequatelytrainedandqualifiedoperators
andmustbecarefullyreadandconservedforfuturereferen-
ce.
Chapters “2RESIDUAL RISKWARNINGS” and“4OPERA-
TING INSTRUCTIONS” contain all the information that DEA
Systemprovides inorderfor theproductto constantlysatisfy
theEssentialSafetyRequirementsprescribedbytheMachinery
Directive(EuropeanDirective2006/42/CE). Readthesechap-
terscarefullybecausetheycontainimportantinstructionsforsafe
installation,useandmaintenanceandimportantwarningsre-
gardingtheresidualrisksremainingevenafterallthesafetyde-
vicesandmeasuresdescribedhavebeenapplied.Theproduct
isdesignedforinstallationincompleteclosingsystemssubject
tospecificlegislation.Chapter6“COMPLETECLOSINGASSEM-
BLY”providesusefulinformationfortherespectoftheEssential
SafetyRequisitesforspecialtypesofclosing.
1 PRODUCT CONFORMITY
DEA System guarantees the conformity of the product to
EuropeanDirectives2006/42/CEregardingmachinerysafety,
2004/108/CEelectromagneticcompatibilityand2006/95/CE
lowvoltageelectricalequipment.DEASystemalsoenclosesthe
manufacturer’sDeclarationofConformitywiththeseinstructions
(seeDirective2006/42/CEArt.4,paragraph2).
2 RESIDUAL RISK WARNINGS
Readthesewarningscarefully;thefailuretorespectthefol-
lowingwarningscancreaterisksituations.
WARNINGTheuseoftheproductunderunusualconditions
notforeseenbythemanufacturercancreatesituationsofdan-
ger,andforthisreasonalltheconditionsprescribedinthese
instructionsmustberespected.
WARNING Under no circumstances must the product be
usedinexplosiveatmospheresorsurroundingsthatmaypro-
vecorrosiveanddamagepartsoftheproduct.
WARNINGAllinstallation,maintenance,cleaningorrepair
operations on any part of the system must be performed
exclusively by qualified personnel with the power supply
disconnectedworkinginstrictcompliancewiththeelectrical
standardsandregulationsinforceinthenationofinstallation
WARNING All other adjustment/setting operations beyond
theadjustmentofthelimitswitchcamsandofthemechanical
clutcharemadebythemanufacturer.Tamperingwiththese
settings may cause malfunction and/or situations of risk to
people,animalsandproperty.Refrain fromperformingany
operationsnotauthorisedbyDEASystem. 
WARNINGTheuseofsparepartsnotindicatedbyDEASy-
stemand/orincorrectre-assemblycancreaterisktopeople,
animalsandpropertyandalsodamagetheproduct.Forthis
reason,alwaysuse onlythepartsindicatedbyDEA System
andscrupulouslyfollowallassemblyinstructions.
WARNING Awareness of the operation of the key-release
mechanism(seeF9Page32)isessentialforallusersofthe
automatism because the failure to use the device quickly
duringemergenciescanjeopardisepeople,animalsandpro-
perty.EnclosureItotheseinstructions,whichtheinstalleris
requiredtodelivertothefinaluser,illustratesoperationand
canbedetached. 
WARNING  DEA System reminds all users that the se-
lection, positioning and installation of all materials and
deviceswhichmakeupthecompleteautomationsystem,
must comply with the European Directives 2006/42/CE
(Machinery Directive), 2004/108/CE (electromagnetic
compatibility),2006/95/CE(lowvoltageelectricalequip-
ment).Inordertoensureasuitablelevelofsafety,besides
complyingwithlocalregulations,itisadvisabletocomply
alsowiththeabovementionedDirectivesinallextraEu-
ropeancountries.
WARNINGToensureanappropriatelevelofelectricalsafety
alwayskeepthe230Vpowersupplycablesapart(minimum
4mmintheopenor1mmthroughinsulation)fromlowvolta-
gecables(motorspowersupply,controls,aerialandauxiliary
circuitspowersupply),andfastenthelatterwithappropriate
clampsneartheterminalboards.
WARNINGAnyexternalsafetydeviceinstalledinordertocon-
formtothelimitssetforimpactforcesmustcomplywithEN12978.
