EN-6
WIRING DIAGRAM ROCK
Closing limit switch (FCC)
Common of the limit switch
Opening limit switch (FCA)
Microswitch of the head
+24 (LED) / +24 (Limit switch)
Buzzer
-24 (LED)
Common of the Pressure switch
Pressure switch
Grounding
Phase (solenoid valve) - 230V
Neutral (solenoid valve) - 230V
Motor march (CLOSE)
Motor march (OPEN)
Common
Microswitch of the head
F
N
3 x 1,5 mm
2
OMNIPOLAR CIRCUIT BRAKER
POWER SUPPLY
230V~ 50Hz ±10%
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Black
Violet
Red
Pink
White
Brown
Green
Grey
Yellow
Yellow/green
Black 5
Black 4
Black 3
Black 2
Black 1
Blue
2
1
910 1112
13 14
15 16
17
18
19
20
21
22
23
24
25
26
27
28
30 2932 31
34 5 678
WARNING
LOCK
FLASH
230V
MOT 1 MOT 2
34 33
WL/FL24V
N
F
ENC_M2ENC_M1
CON 1
CON 2
COM
IN_1
COM
IN_2
COM
IN_3
COM
IN_4
COM
IN_5
COM
IN_6
DISPLAY
Serial N°
000X XXXXXX
ATTENTION The total absorption of the integrated standard components
supplied with 24V is ~100mA (limit switch, LED head, buzzer).
ATTENTION For the wiring of 2 bollards to a single control unit NET230N,
it will be necessary to provide a separate power source for any 24V
accessories that should normally be connected to the +24VAUX and
+24_ST outputs (photocells, radio receivers, etc.).
