MD‐CROSSOPERATINGMANUALVERSION1.0
Copyright©2013DecimatorDesignPtyLtd,Sydney,Australia
11
14.AudioMeter/GreenStart(HasSUB‐MENUwithparameter)
Thisisthestartinglevelforthegreenrangeontheaudiometer.Thevaluedefaultis‐20dBFS.
Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.
Pressthe<and>buttonstoincreaseanddecreasethelevelrespectivelyfrom0to‐100dBFS.
Press
theBACKbuttontoleavethisSUB‐MENU.

15.AudioMeter/BarThickness(HasSUB‐MENUwithparameter)
Thisisthethicknessoftheaudiometer.Thevaluedefaultis6.
Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.
Pressthe<and>buttonstodecreaseandincreasethethicknessrespectivelyfrom2to24.
PresstheBACKbuttontoleave
thisSUB‐MENU.

16.AudioMeter/Margin(HasSUB‐MENUwithparameter)
Thisisthedistancetheaudiometersarefromthesideofthescreen.Thedistanceisshownin
percentageofthescreenresolution.Thedefaultvalueis5%.
Whenthesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.
Pressthe<and>buttonstodecreaseandincreasethethicknessrespectivelyfrom0%to25%.
PresstheBACKbuttontoleavethisSUB‐MENU.


Graticules:(HasSUB‐MENUs)

Graticules
Safe Action
Off

MainMenu <==
SubMenu
ParameterWindow
WhenhighlightedintheMainMenu,presstheENTERbutton toenterthissub‐menu.
Pressthe<and>buttonstomoveleftorrightrespectivelythroughthe18menusbelowandpress
theBACKbuttontogobacktotheMainMenuwhenfinished.
Thecurrentvalueforeach
SubMenuisshownintheParameterWindow.

1.Graticules/SafeAction(Parameter)
Thisenablesthesafeactiongraticuleoverlay.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingselections:
1.) Off
2.) On

2.Graticules/SafeTitle(Parameter)
Thisenablesthesafetitlegraticuleoverlay.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingselections:
1.) Off
2.) On

3.Graticules/CentreCross(Parameter)
Thisenablesthecentrecrossgraticuleoverlay.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingselections:
1.) Off
2.) On

4.Graticules/Anamorphic(Action)
Whenthesubmenuishighlighted,pressENTERtosetsthegraticuleaspecttoanamorphic.

5.Graticules/16:9LBon4:3(Action)
Whenthesubmenuishighlighted,pressENTERtosetsthegraticuleaspectto:
16:9Letter‐boxona4:3Raster



