DEFENDER
®
COMPACT BASE
85103
ENGINEERING DRAWING
Accessories:
A 810 mm / 31.9" E 23 mm / 0.9" I 28 mm / 1.1" M 22 mm / 0.9"
B 25 mm / 1.0" F 27 mm / 1.1" J 410 mm / 16.1"
C 830 mm / 32.7" G 29 mm / 1.1" K 235 mm / 9.3"
D 37 mm / 1.5" H 30 mm / 1.1" L 21 mm / 0.9"
