DEL RollEnergy Evolution - Page 24

25
5 cm
mini
For concrete and panel pools
PUSH-LOCK INSTALLATION
For concrete and panel pools
50 mm
water level
Acceptable limit of
level variation
50 mm
Hang mounted version
Insert mounted model
Installation
A water level regulator is mandatory
50 mm
50 mm
recommended
5 cm
mini
50 mm
50 mm
For concrete and concrete block pools, as well as pools with
wall thickness greater than or equal to 8 mm
Surface mounted model
60 mm “minimum”
Once the resistance
point has been
reached stop screwing,
this would deteriorate
the fixture quality.
Concrete
After reaching the
resistance point, make
3 more turns of the
screwdriver
to finish tightening.
Concrete block
Plug
Washer
Washer
5 cm
Ø8
Ø12
VBA TF Z pozi
stainless steel A4 Ø6
x 60 wood screw
Screw cap
Hollow white
Ø16 washer
Inserted
part
Screw cap
Hang mount support
Ø12 Nylon
plug
Stainless steel nut
A4 M10
Cale
13 mm
VBA TF Z pozi
stainless steel A4
Ø6 x 60 wood screw
Hollow white
Ø16 washer
INOX
M6 washer
water level
Acceptable limit of
level variation
recommended
water level
Acceptable limit of
level variation
recommended
Universal 8 x 40 plug
VBA TF Z pozi stain-
less steel A4 Ø6 x 60
wood screw
Hollow white Ø16
washer
Screw cap
