3
Description
NECESSARY TOOLS - (INSTALLATION - 2 PERSONS)
PACKING LIST
example - for a 5 x 10 m pool with Ø3 m step unit
Support + control box : 1 box of 0.65 x 0.45 x 0.25 --- 40 Kg
Tube with motor : 1 box of 0.20 x 5.10 m --- 40 Kg
Aluminum beam : 1 box of 0.15 x 0.15 x 5.10 m --- 40 Kg
Beam support : 1 box of 0.30 x 0.20 x 0.20 m ---10 Kg
Decking : 1 pallet of 1.20 x 1.00 x 0.50 m --- 100 Kg
Slats : 5 box of 0.25 x 0.20 x 5.00 m --- 250 Kg
locking kit : 1 box of 0.30 x 0.20 x 0.20 m or 0.75 x 0.25 x 0.15 m --- 5 KG
Total weight : 485 Kg
Aluminium beam
“Model according to your order” (1 box)
Middle telescopic support
(1 box)
Hanging and surface
mount
Insert mount
support
(for pool width > to 6 m)
Decking “Model according to your order” (1 pallet)
Ø8 - 12 - 20
n°10
n°13
n°17
Exotic wood IPE
«OPTION»
