6
Installation
CHARACTERISTICS AND COVER PIT DIMENSIONS
The sides of the cover pit must be vertical and parallel between them.
The dimension I
(minimum distance of the cover p
i
must be taken at the end of th
e
radius or the cut side.
Concrete separation wall
Main drain
skimmer
L = Pool length (step unit and cover pit)
With straight radius or radius and cut sides <= to 10 cm back of the cover pit
With radius and cut sides > to 10 cm back of the cover pit
water level
regulator
Sécuriwall
Sécuriwall
Main drain
skimmer
M
inimum
distance of
the cover
p
i
t
L = Pool length (step unit and cover pit)
water level
regulator
I
M
inimum
distance of
the cover
p
i
t
I
I
L
(en m)
< 6 6 à 7 7 à 8 8à9 9à10 10à11 11à12 12à13 13à14 14à15 15 à16 16à17
I
(en mm)
548 574 598 621 643 664 684 703 722 740 758 775
L
(en m)
17à18 18à19 19à20 20à21 21à22 22à23 23à24 24à25 25à26 26à27 27à28 28à30
I
(en mm)
791
mm
807
mm
823
mm
839
mm
854
mm
869
mm
883
mm
897
mm
911
mm
925
mm
938
mm
965
mm
