6
6 cm
34 cm
24 cm
Alimentation 230 V
Electrolyseur
(U1000RO2V sous gaine)
selon la norme en vigeur
LED
30 cm
mini
LED
Installation
Remember to have a sheath
fitted to connect the electric
control box and the motor
terminal.
D + 6 cm
see positioning
rules 1
page 8
D = (measurement between the
terminal - pool width) / 2
ELECTRIC version
SOLAR version
Place the solar panel on the
sunniest side
Instructions before installation
