EZ4040G PUMP COMPONENT LOCATOR PARTS LIST
Ref. No. Qty. Part No. Description
1. 1 44.1200.41 Manifold (15 mm) / Collector
2. 8 99.3175.00 Screw / Tornillo
3. 8 96.7014.00 Washer / Arandela
4. 6 90.3841.00 O-Ring (Kit No.123) / Empaque-O (Kit No.123)
5. 6 36.2003.66 Valve Seat (Kit No. 123) / Asiento de Válvula
6. 6 36.2001.76 Valve (Kit No. 123) / Válvula
7. 6 94.7376.00 Spring (Kit No. 123) / Resorte
8. 6 36.2025.51 Valve Cage (Kit No. 123) / Jaula de Válvula
9. 6 90.3847.00 O-Ring (Kit No. 124) / O-Anillo
10. 6 98.2226.00 Cap Screw (Kit No. 124) / Capuchón de la Muelle
11. 6 36.7115.01 Valve Assembly (Kit No. 123) / Ensamblaje de Válvula
12. 4 99.1807.00 Screw / Tornillo
13. 1 50.1500.74 Bearing Cover / Protección de Cojinete
14. 1 44.2118.01 Spacer / Espaciador
15. 1 90.4097.00 O-Ring / Empaque-O
16. 1 91.8328.00 Ball Bearing / Cojinete de Bolas
17. 3 90.1614.00 Oil Seal (Kit No. 23) / Sello del Aceite
18. 1 44.0100.22 Crankcase / Cárter
19. 1 98.2103.00 Oil Dip Stick / Varilla del Nivel de Aceite
22. 3 44.0501.66 Plunger Guide / Guía de Émbolo Buzo
23. 3 44.0300.22 Connecting Rod / Biela de Conexión
24. 1 90.3920.00 O-Ring / Empaque-O
25. 1 44.1600.22 Rear Cover / Revestimiento Trasero
26. 5 99.1837.00 Screw / Tornillo
27. 1 90.3585.00 O-Ring / Empaque-O
28. 1 98.2041.00 Cap Screw /
29. 3 97.7340.00 Pin / Pasador
30. 3 99.6967.00 Washer / Arandela
31.
32.
33. 3 44.0402.66 Plunger, 13 mm /
34.
35.
40. 3 90.3612.00 O-Ring (Kit No’s.152, 156) / O-Anillo
41. 3 44.0803.70 Packing Retainer (Kit No’s.152, 156) / Retenedor de Junta
42. 3 44.2162.70 Intermediate Ring (Kit No.’s 154, 156) / Anillo Intermedio
43. 3 90.5076.00 Packing (Kit No’s. 153, 156) / Junta
44. 3 90.2602.00 Packing (Kit No’s. 153, 156) Junta
45. 3 44.1002.51 Head Ring (Kit No’s. 155, 156) /
46. 1 98.2100.00 Cap Screw / Capuchón del Tornillo
47. 1 98.2176.00 Cap Screw / Capuchón del Tornillo
48. 1 96.7380.00 Washer / Arandela
49. 1 96.7514.00 Washer / Arandela
50. 1 98.1966.00 Cap Screw / Capuchón de la Tornillo
51. 3 90.2603.00 Seal, Low Press. (Kit No’s. 153, 156) /
75. 1 90.0635.00 Retaining Ring / Anillo de la Retencion
76. 1 44.0221.65 Crankshaft (EZ3040G) / Cigüeñal
77. 1 91.8568.00 Roller Bearing / Cojinete
78. 1 90.4097.00 O-Ring / Empaque-O
79. 4 99.2755.00 Screw, 5/16x1 / Tornillo, 5/16x1
99. 4 99.3345.00 Screw, 3/8x1 / Tornillo, 3/8x1
80. 4 96.7020.00 Washer, Ø8 mm / Arandela, Ø8 mm
96. 4 96.7104.00 Washer, Ø10 mm / Arandela, Ø10 mm
81. 1 10.0518.22 Gas Flange / Brida
82. 1 90.1690.00 Oil Seal / Sello del Aceite
83. 4 96.6938.00 Washer / Arandela
84. 4 99.1912.00 Screw / Tornillo
Kit No. 23 inlcudes Ref. No’s: 17 Kit No. 153 includes Ref. No’s: 43, 44, 51
Kit No. 89 includes Ref. No’s: 42 Kit No. 152 includes Ref. No’s: 40, 41
Kit No. 123 includes Ref No’s: 4,5,6, 7, 8, (11) Kit No 154 includes Ref. No’s: 42
Kit No. 124 includes Ref No’s: 9, 10 Kit No. 156 includes Ref. No’s: 40, 41, 42, 43, 44, 45, 51
