WIRELESS KINETIC WALL SWITCH CONTROL UNIT
USER MANUAL AND INSTALLATION GUIDE
PRODUCT INFORMATION:
The control unit of Delight’s latest wireless, KINETIC switch family, which can be connected to most circuits,
thus switching the consumer. You must also purchase one of the 55352, 55353 switches available from
Delight to use this product! Purchasing per unit allows for a modular design so everyone can create a switch
network to suit their own needs.
HOW IT WORKS:
Any consumer with a power not exceeding 500 W (100 V-230 V AC (50 / 60 Hz) operating voltage) can be
connected to the control unit. Consumers connected to this control unit can be switched on and o using the
button on the top of the device or one of the wireless KINETIC switches. The control unit is easy to teach, it can
handle several switches at the same time, so it can be installed as a toggle switch.
ATTENTION! PRIOR TO MOUNTING, MAKE SURE THAT THE CIRCUIT IS DE-ENERGIZED!
PAY ATTENTION TO THE CORRECT CONNECTION, IF YOU ARE UNSURE, ALWAYS SEEK
PROFESSIONAL HELP!
Input voltage: 100 - 230 V AC (50/60 Hz) Communication mode: FSK
Max. power: 500 W (min. 5 W) Power transmission: +10 dBm
Max current: 10 A Lifetime: +200000 switching
cycle
Built in glass fuse: 10 A / 250 V Mounting: Screw, anchor, double
sided tape (included)
Operating temperature: 10 - 50 °C Protection: IP20
Operating radio frequency: 433 MHz Size: 60 x 52 x 28 mm
Range: max. 100 m Color: White
Operation type: 86 Weight: ~50 g
WARNINGS:
DANGER OF SUFFOCATION!
•
Please keep the packaging of the appliance out of the reach of children as it may lead to suocation. The
appliance may only be used by adults, the storage location must be chosen in such a way that children cannot
accidentally access it. Children should be supervised to ensure that they do not play with the appliance.
•
The device may only be used for its intended purpose! The device may only be used by people who have
read, understood and are able to operate this device accordingly! People with reduced mental, physical or
sensory capabilities should not use the device! Children should not use the appliance! The device is designed
for residential use!
•
Do not use the device if you have previously dropped or struck it and it is visibly damaged! It is strictly
forbidden to use, modify or disable safety devices!
DANGER OF ELECTRIC SHOCK!
•
If you are unfamiliar with connecting electrical equipment to the mains, seek professional assistance from
an electrician!
•
Always de-energize the circuit before connecting the device! Use a phase tester to make sure there is no
voltage in the wires.
•
DO NOT operate the control unit with a free cable end! Only switch on the appliance if you have connected all
the cables and made sure that they are connected correctly!
•
Attention! The device is equipped with a 10A glass fuse, which is strictly forbidden and life-threatening to bypass!
•
Do not use the device in a humid, environment, the device may only be used indoors in a dry area. Otherwise
there is a risk of short circuit and electric shock!
•
Thanks to the compact size, it is possible to hide the control unit, but even in such an installation, make sure
that the device is properly ventilated!
•
Only operate the device with the specied voltage (100 - 230 V AC)!
•
Do not touch the device with wet hands! It is strictly forbidden to touch the device, including the cable,
with wet hands!
•
Before applying power to the device, check that the connection is correct and that the insulation is intact.
Improper wiring can lead to accidents and property damage!
•
Depending on the power of the consumer connected to the device, choose the cable required for connection,
we recommend using cables with a cross section of at least 2 x 1 mm
2
! During use, pay attention to the
integrity of the mains cable, avoid edges or objects that can damage the surface of the cable.
