Dell 7810 - Page 5

Page 5 of 15
Dave Pimm – Avid Technology – Sept 1st, 2016
Rev D
AVID qualified HBA info
AVID qualified
HBA
AVID Part
Number
Slot
Location
Function
Vendor qualified 3
rd
party
X8 PCI-E or lesser
interface
Not stocked by
AVID
#1
¾
Length
PCI
form
factor or
smaller
Vendor qualified 3
rd
party hardware interface.
See release notes and Avid website for
information regarding supported 3
rd
party
hardware
Avid Artist DnxIO HBA **
Active: 7030-30048-02
Active: 7030-30048-01
#1
Avid Artist DnxIO interface HBA
Avid HIB, DX Interface
Active: 7030-30048-02
Active: 7030-30048-01
Active: 7030-20084-01
#5
Avid DX Hardware Interface HBA
Atto R680
Not stocked by
AVID
#4
Local SAS Storage Support
– Avid VideoRAID ST (5-
bay) Xtore StudioRAID 5Ti
(5-bay)
LSI 9200-8e SAS
controller
7030-30036-01
#4
SAS Local Storage:
Xtore StudioRAID 16Re (16-bay)
chassis Xtore StudioRAID 5Te (5-bay)
chassis
Intel PRO 1000 PT
7030-20139-01
#4
Shared Storage: Unity ISIS Copper Gb-Ethernet
Dual Gb ISIS Connectivity
Intel i350-T2 – Dual Gb
NIC
Not stocked by
AVID
#4
Shared Storage: Unity ISIS Copper Gb-Ethernet
Dual Gb ISIS Connectivity
Intel PRO 1000 PF - ISIS
Not stocked by
AVID
#4
Shared Storage: Unity ISIS Optical Gb-Ethernet
Myricom 10G-PCIE-8B-S
Myricom 10G-PCIE-8B2-
2S
7030-30041-01
#4
Shared Storage: Unity ISIS 10Gb-Ethernet
for Hi-Res client (ISIS 5000 / 7000)
Red Rocket Accelerator
Not stocked by
AVID
#4
Accelerator for RED files
** Avid DX Interface HBA Support Note: (See reference pictures on page 7 of this guide).
All 3 versions of the DX interface HBA are supported on the 7810 with Media Composer / Symphony
8.x
1) Active DX interface HBA 7030-30048-01 (also for Artist DNxIO)
2) Active DX interface HBA 7030-30048-02 (also for Artist DNxIO)
3) Active DX interface HBA 7030-20084-01 (cannot be used with Artist DNxIO)
