1. Measured in accordance with ISO IEC 27434/35 methodology. Actual print speeds will vary with use.
2. 1 MB means 1 million bytes, 1 GB means 1,000 megabytes or 1,000,000,000 bytes; total accessible capacity varies depending on operating environment.
3. Duty cycle is dened as the maximum number of imaged outputs a device could deliver in a month. This metric provides a comparison of robustness in relation to other Dell printers and multifunction printers.
4. The printer and the mobile device must be connected on the same network.
5. AirPrint-enabled printers work with iPad, iPhone (3GS or later), and iPod touch (3rd generation or later) running iOS 4.2 or later.
©2013 Dell Corporation Limited. Dell, the Dell logo and Dell Toner Management System are registered trademarks or trademarks of Dell Inc. Other trademarks and trade names may be used in this document to refer to either
the entities claiming the marks and names or their products. Dell disclaims proprietary interest in the marks and names of others. Microsoft, Windows and Windows NT are registered trademarks or trademarks of Microsoft
Corporation. Android and Google Cloud Print are registered trademarks of Google Inc. iPad, iPhone, iPod, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. AirPrint and the AirPrint logo are
trademarks of Apple Inc. Dell Products, Dell House, The Boulevard, Cain Road, Bracknell, Berkshire, RG12 1LF, UK. Product availability varies by country. Please contact your Dell representative for more information.
Specications are subject to change without notice. Dell cannot be responsible for errors and omissions in typography or photography.
A13002261 - C2660dn - Oct 2013
Product Specifications
Printer specifications Print speed (Mono/Colour)
Simplex (600 x 600 dpi) Up to 27 ppm
1
(A4)
Duplex (600 x 600 dpi) Up to 18 ppm
1
(A4)
First page out time from
Ready state
Less than or equals to 14 seconds (simplex)
Print resolution 600 x 600 dpi (up to 2400 dpi image quality)
Operation panel LCD: 4 Lines Bitmap based Mono LCD, font scalable; 10-key Numeric pad; Viewing Area: 1.97” (49.97 mm) (W)
x 0.8” (19.17 mm)(L); Backlight: White backlight; Status LED: 1 LED (combination “Data Green/Error Amber”)
Power Saver Button (Light on/o)
Print language
Printer Driver Language PCL6, PostScript
TM
3, XPS
Printer data stream (FW) PCL5C, PCL 6 (PCLXL 2.1), PostScript 3
Fonts HP PCL
®
6 Emulation: 80 scalable fonts
PostScript
®
Level 3 : 80 scalable fonts
Processor speed 525 MHz
Memory 512 MB
2
Maximum duty cycle Up to 50,000 pages per month
3
Recommended monthly
print volume
450 - 4,000 pages per month
Mobile printing support Dell Mobile Print
4
(Android™ OS), AirPrint
5
(iOS). Google Cloud Print
Printer management Dell Printer Conguration Web Tool, Dell ColourTrack 2.2, Dell Toner Management System, Dell Open Print Driver (OPD), Dell OpenManage
TM
Printer
Manager v2 (OMPM)
Security features Print Job Management Secure Print with 4 Digit Pin, Virtual Mail Box, Print Job disable/enabling scheduling
Network Authentication SNMP V3
Data Encryption Ipsec (IKev1)/Pre-shared key
Access Control Management Embedded Web Server access control of Enable/Disable of network port & Protocol , printer settings &
report access, Operator Panel access
I/O Access control Protocol base (Network)
Colour Control Dell ColourTrack 2.2
Lock type and location Kensington lock for printer, primary input tray, optional input drawer and accessories (wireless dongle)
Standard media types,
sizes and paper weights
Standard tray
Media types and weights supported Plain paper (60-90 gsm), Thicker paper (91-105 gsm), Heavier paper (106-216 gsm), Preprint (60-163 gsm),
Letterhead (60-163 gsm), Prepunched (60-105 gsm), Cardstock (106-216 gsm), Coated paper (95-216 gsm),
Recycled paper
Media sizes A4 Short Edge Feed (SEF), B5 SEF, A5 SEF, US Letter SEF, Executive SEF, Foilio (8.5”x 13”) SEF, US Legal SEF
Custom size: 148 mm – 215.9 mm (W), 210 mm – 355.6 mm (L)
Multipurpose tray
Media types and weight supported Plain paper (60-163 gsm), Preprinted (60-163 gsm), Letterhead (60-163 gsm), Prepunched (60-105 gsm),
Cardstock (106-216 gsm), Heavier paper (164-216 gsm), Coated paper (95-216 gsm), Recycled paper,
Labels, Envelope, Hagaki cards
Media sizes A4 SEF, B5 SEF, A5 SEF, US Letter SEF, Executive SEF Folio (8.5” x 13”) SEF, US Legal SEF, Envelope Com-10
(SEF), Envelope Monarch (SEF), Envelope DL (LEF/SEF), C5 (SEF), Post Card
Custom size: 76.2 mm – 216 mm (W), 127 mm – 355.6 mm (L)
Optional Tray
Media types and weights supported Plain paper (60-90 gsm), Thicker paper (91-105 gsm), Heavier paper (106-216 gsm), Preprint (60-163 gsm),
Letterhead (60-163 gsm), Prepunched (60-105 gsm), Cardstock (106-216 gsm), Coated paper (95-216 gsm),
Recycled paper, Labels
Media sizes A4 SEF, B5 SEF, A5 SEF, US Letter SEF, Executive SEF, Folio (8.5”x 13”) SEF, US Legal SEF
Custom size: 148 mm – 215.9 mm (W), 210 mm – 355.6 mm (L)
Duplexer
Media types and weights supported Plain paper (60-90 gsm), Thicker paper (91-105 gsm), Heavier paper (106-163 gsm), Recycled paper, Coated
paper (95-163 gsm)
Media sizes US Letter SEF, Executive SEF, A5 SEF, A4 SEF, B5 SEF, US Legal 13 SEF, US Legal 14 SEF
Custom size: 148.5 mm – 215.9 mm (W), 210 mm – 355.6mm (L)
Printable area 207.9 mm x 347.6 mm
Paper handling Standard input sources 250-sheet standard tray, 150-sheet multipurpose tray
Additional input capacity 550-sheet option drawer
Maximum input capacity 950 sheets (via addition of one 550-sheet optional drawer)
Duplexer Automatic two-sided printing (default)
Standard output capacity 250 sheets
Maximum output capacity 250 sheets

Other manuals for Dell C2660dn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell C2660dn and is the answer not in the manual?

Dell C2660dn Specifications

General IconGeneral
ColorYes
Print technologyLaser
Maximum resolution600 x 600 DPI
Duplex printing modeAuto
Print speed (black, normal quality, A4/US Letter)27 ppm
Duplex print speed (black, normal quality, A4/US Letter)18 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle50000 pages per month
Recommended duty cycle750 - 3500 pages per month
Number of print cartridges4
Page description languagesMicrosoft XPS, PCL 6, PostScript 3
Paper input typePaper tray
Total input capacity400 sheets
Total output capacity250 sheets
Maximum input capacity950 sheets
Envelopes sizes10, C5, DL, Monarch
Maximum print size216 x 356 mm
Paper tray media typesCoated paper, Envelopes, Heavy paper, Labels, Plain paper, Recycled paper, Thick paper
Paper tray media weight60 - 216 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size)
ISO A-series sizes (A0...A9)A4, A5
ISO B-series sizes (B0...B9)B5
ISO C-series sizes (C0...C9)C5
Maximum ISO A-series paper sizeA4
Wi-FiNo
Security algorithmsSSL/TLS
Mobile printing technologiesNot supported
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantity5
Noise level (idle)25.5 dB
Maximum internal memory- MB
Sound pressure level (printing)53 dB
DisplayLCD
CertificationGS, RoHS, WEEE, ErP Lot 6
Product colorBlack
Display number of lines4 lines
AC input voltage230 V
Power consumption (printing)- W
Sustainability certificatesBlue Angel, ENERGY STAR
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Linux operating systems supportedRedHat EL Linux 5.0, SuSE Linux 10, SuSE Linux 11
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)10 - 32 °C
Operating relative humidity (H-H)10 - 85 %
Package depth686 mm
Package width570 mm
Package height526 mm
Package weight30500 g
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth485 mm
Width439 mm
Height379 mm
