70 Appendix
www.dell.com | support.dell.com
Memory
Architecture DDR SDRAM
Memory connectors two
Memory capacities 128-, 256-, or 512-MB
Minimum memory 128 MB shared DDR SDRAM
NOTE: Between 32 and 64 MB of system memory may be
allocated to support graphics, depending on system
memory size and other factors.
Maximum memory 1 GB
Memory type PC2100 (266-MHz) or PC2700 (333-MHz) DDR
SDRAM (non-ECC)
Drives
Externally accessible two 5.25-inch bays
one 3.5-inch bay
Internally accessible one bay for 1-inch–high IDE hard drive
Ports and Connectors
Externally accessible:
Serial
9-pin connector; 16550C-compatible
Parallel
25-hole connector (bidirectional)
Video
15-hole connector
Keyboard
6-pin mini-DIN connector
Mouse
6-pin mini-DIN connector
USB
two front-panel and four back-panel USB
2.0–compliant connectors
Network
RJ-45 connector
Audio
three back miniature connectors for line-in, line-out,
and microphone
Headphone
one front miniature connector for line-out
