6. Restart your system.
Initializing the TPM 2.0 for users
Steps
1. While booting your system, press F2 to enter System Setup.
2. On the System Setup Main Menu screen, click System BIOS > System Security Settings.
3. From the TPM Security option, select On.
4. Save the settings.
5. Restart your system.
LOM and rear IO card
Removing the rear Input Output card and LOM card
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in Before working inside your system.
3. Remove the system board.
Steps
1. Using a Phillips #2 screwdriver, remove the screws that secure the rear Input Output (RIO) card and LOM card to the
system board.
2. Holding the edges, pull the RIO card and LOM card to disconnect from the connector on the system board.
NOTE: The procedure to remove RIO on liquid cooling configuration is same.
Figure 131. Removing the RIO card
Installing and removing system components
145
