272 | Border Gateway Protocol IPv4 (BGPv4)

www.dell.com | support.dell.com

Figure 10-37. Sample Configuration Illustration

GigE 1/31

10.0.3.31 /24

Loopback 1

192.168.128.1 /24

GigE 2/31

10.0.2.2 /24

Loopback 1

192.168.128.2 /24

Physical Links

Virtual Links

GigE 1/21

10.0.1.21 /24

ck 1

/24

GigE 2/11

10.0.1.22 /24

GigE 3/11

10.0.3.33 /24

Loopback 1

192.168.128.3 /24

GigE 3/21

10.0.2.3 /24

AS 99

AS 100

Peer Group BBB

Peer Group AAA

Peer Group CCC
