26 | SFTOS Features
www.dell.com | support.dell.com
• Software naming convention: E-Series software uses this naming convention: FTOS-EF-x.x.x.x
Through version 2.3.1.5, the S-Series used a different format that ends with an “.opr” extension.
Starting with SFTOS 2.4.1, SFTOS software image file names have a new naming format that is more
descriptive and is consistent with the E-Series software naming convention:
"SFTOS-<platform>-<version>-<switching | routing>.bin"
for example: SFTOS-S2410-2.4.1.1-switching.bin.
Port Naming Convention
SFTOS supports stacking (one virtual switch made by connecting several switches) with the port naming
convention “
unit/slot/port<lucindaRgOb>”. For example, in show interface 1/0/11, 1/0/11 represents unit 1
in the stack, slot 0, port 11. If the port were in unit 2 of the stack, the command should be
show interface 2/
0/11.
In more detail, the physical entities that define this convention are as follows:
• Unit—The switch ID in a stack of switches (begins with the number 1, so the ports of a standalone
switch are numbered
1/slot/port).
• Slot—slot numbers for modular entities within the switch. Although S-Series switches have optional
port modules that might qualify for a slot number, S-Series switches currently always list the slot
number as 0 (listing all physical ports as
unit/0/port) unless representing a logical entity, such as a port
channel.
• Port—physical interface (port numbers are sequential starting at 1).
Logical interface identifiers are automatically generated by SFTOS. They also use the unit/slot/port
convention, but:
• Logical unit numbers are always 0.
• Logical slot numbers are sequential and start with a 1.
• Logical interface numbers (in the third position) are also sequential starting at 1 for each slot.
VLAN routing interfaces and port channels (LAGs) are logical entities. Logical interface identifiers are
defined by the system upon creation.
