Dell inspiron 27 7000 - Procedure

141 pages

To Next Page

To Previous Page

Identifier GUID-42D53C65-E4EC-4D23-8E57-0591692982E6

Status Released

Procedure

1 Locate the solid-state drive slot on the system board.

2 Remove the screw (M2x3.5) that secures the solid-state drive to the system

board.
