Removing the Optical Drive | 15
3 Remove the screw that secures the optical-drive bracket to the
optical-drive assembly and remove the optical-drive bracket.
4 Carefully pull the optical-drive bezel and remove it from the optical drive.
1 optical-drive bezel 2 optical drive
3 optical-drive bracket 4 screw
3
2
4
1
