Adding and Replacing Parts 85
5
Install the replacement Mini PCI card:
a
Align the Mini PCI card with the connector at a 45-degree angle, and press the Mini PCI card into
the connector until it clicks.
NOTICE: To avoid damaging the Mini PCI card, never place cables under the card.
b
Connect the antenna cables to the Mini PCI card.
Mini PCI card
antenna cables
