Dell Latitude 3189 - Touchpad panel removal and installation

Installing speakers
1 Place the speakers into the slots on the computer.
2 Route the speaker cable through the retention clips through routing channel.
3 Ax the adhesive tape to secure the speaker cable on the computer.
4 Connect the speaker cable to the connector on the system board.
5 Install the:
a battery
b base cover
c microSD card
6 Follow the procedure in After working inside your computer.
Touchpad panel
Removing touchpad
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a microSD card
b base cover
c battery
d speaker
3 To remove the touchpad cable:
a Lift the latch, and disconnect the touchpad cable from the computer [1].
b Remove the touchpad cable [2].
24
Removing and installing components
