Installing world facing camera
1 Insert the camera into the slot on the computer.
2 Ax the tape to secure the camera on the palm rest assembly.
3 Install the:
a system board
b touchpad
c speaker
d coin cell battery
e power connector
f audio
g power switch board
h SSD card
i keyboard
j battery
k base cover
l microSD card
4 Follow the procedure in After working inside your computer.
Palm rest
Replacing the palm rest
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a microSD card
b base cover
c battery
d keyboard
e SSD card
f power switch board
g audio
h power connector
i coin cell battery
j speaker
k touchpad
l display assembly
m system board
n world facing camera
NOTE
: The component you are left with is the palm rest.
