Steps
1. Loosen the eight captive screws that secure the base cover to the palmrest assembly.
2. Using a plastic scribe, pry open the base cover starting from the recesses located in the U-shaped indents near the hinges at
the top edge of the base cover.
3. Carefully lift and remove the base cover from the chassis.
NOTE: Be careful of the latches while removing the base cover as the latches may break.
Installing the base cover
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the battery and provide a visual representation of the installation procedure.
Removing and installing components 19
