Screw size list
Table 1. Latitude 7290 screw size list
Component M2.5 x 6.0 M2.0 x 5.0 M2.5 x 3.5 M2.0 x 3.0 M2.0 x 2.5 M2.0 x 2.0
Back cover 8 (captive
screws)
Battery—3-cell 1
Battery—4-cell 2
SSD module 1
Heat sink module 4
System fan 2
Speaker 4
WWAN card 1
WLAN card 1
Power connector
port
1
ESD bracket 1
EDP bracket 2
LED board 1
Smart card
reader cage
2
Display hinge 6
Keyboard support
plate
19 5
Keyboard 5
System board 8
Memory module
bracket
1
LCD cover 4 2
Touchpad button 2
Fingerprint 1
USB Type B
bracket
2
Thermal module 4
Thermal Fan 2
SSD holder 1
Battery 2
Removing and installing components 7
