Dell OptiPlex XE3 Small Form Factor Service Manual

6. Remove the heat sink with fan:
a) Disconnect the heat sink fan cable from the system board [1].
b) Loosen the 4 captive screws that secure the heat sink [2] and lift it away from the system [3].
NOTE:
Loosen the screws in a sequential order (1,2,3,4) as mentioned on the system board.
Installing the VGA card 115
