— 14 —
P780
SECTION 7
ELECTRICAL PARTS LIST
RESISTORS
• All resistors are in ohms
• F : nonflammable
• Items marked * are not stocked since they are seldom
required for routine service. Some delay should be
anticipated when ordering these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise noted.
When indicating parts by reference
number, please include the board
name.
REF. NO. PART NO. DESCRIPTION REMARK
REF. NO. PART NO. DESCRIPTION REMAR
K
The components identified by shading
and mark are critical for safety. Replace
only with part number specified.
Note:
Note:
Les composants identifies per un trame et une
marque
sont critiques pour la securite. Ne
les remplacer que par une piece portant le
numero specifie.
The components identified by in this manual have been carefully factory-
selected for each set in order to satisfy regulations regarding X-ray radiation.
Should replacement be required, replace only with the value originally used.
8-933-381-00 A BOARD, MOUNTED
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C001 1-162-318-11 CERAMIC 0.001µF 10% 500V
C002 1-106-220-00 MYLAR 0.1µF 10% 100V
C004 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C007 1-104-664-11 ELECT 47µF 20% 25V
C008 1-104-664-11 ELECT 47µF 20% 25V
C009 1-126-925-11 ELECT 470µF 20% 10V
C010 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C011 1-106-220-00 MYLAR 0.1µF 10% 100V
C012 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C014 1-107-932-11 ELECT 47µF 20% 100V
C015 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C016 1-128-528-11 ELECT 470µF 20% 16V
C017 1-104-664-11 ELECT 47µF 20% 25V
C018 1-107-961-91 ELECT 10µF 20% 250V
C022 1-104-664-11 ELECT 47µF 20% 25V
C027 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C028 1-104-664-11 ELECT 47µF 20% 25V
C029 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C032 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C033 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C035 1-162-134-11 CERAMIC 470pF 10% 2KV
C036 1-104-503-12 CERAMIC CHIP 0.1µF 10% 100V
C042 1-102-074-00 CERAMIC 0.001µF 10% 50V
C044 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C046 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C047 1-104-664-11 ELECT 47µF 20% 25V
C049 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C050 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C053 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C054 1-137-528-11 MYLAR 0.1µF 10% 250V
C055 1-104-503-12 CERAMIC CHIP 0.1µF 10% 100V
C061 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C090 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C092 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C102 1-137-528-11 MYLAR 0.1µF 10% 250V
C104 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C105 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C106 1-137-528-11 MYLAR 0.1µF 10% 250V
C112 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C130 1-216-295-11 SHORT
C151 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C202 1-137-528-11 MYLAR 0.1µF 10% 250V
C204 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C205 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C206 1-137-528-11 MYLAR 0.1µF 10% 250V
C212 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C230 1-216-295-11 SHORT
C251 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C302 1-137-528-11 MYLAR 0.1µF 10% 250V
C304 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C305 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C306 1-137-528-11 MYLAR 0.1µF 10% 250V
C312 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C330 1-216-295-11 SHORT
C351 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
CONNECTOR
CN301 1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
CN303 1-695-915-11 TAB (CONTACT)
CN304 1-695-915-11 TAB (CONTACT)
CN305* 1-564-512-11 PLUG, CONNECTOR 9P
CN306* 1-564-509-11 PLUG, CONNECTOR 6P
CN309* 1-564-511-11 PLUG, CONNECTOR 8P
CN310* 1-779-944-21 PIN, CONNECTOR (PC BOARD) 4P
CN311* 1-564-508-11 PLUG, CONNECTOR 5P
