Dell PowerEdge C6220 - Page 16

Getting Started With Your System | 14
Connectors (Per System Board)
Back
NIC
Two RJ-45 (10/100/1000 Mbps Ethernet)
COM 9-pin, DTE, 16550-compatible
USB
Two 4-pin, USB 2.0-compliant
Video
15-pin D-Sub VGA
Management port RJ-45 Ethernet port for remote management
access. The management LAN speed is
10Mbps/100Mbps.
Internal
Micro-SD socket
SD riser card memory socket
Video (Per System Board)
Video type AST2300 on-board video controller, or
AST1300
Video memory 16 MB
Power
NOTE: The system doesn’t support a mixed installation of 1200 W and 1400 W power supplies.
NOTE: Both of these two PSUs are swappable, and they can support hot swap in any condition if
system has power throttling feature.
AC power supply (per power supply)
Wattage
1200 W
Voltage 100-240 VAC, 50/60 Hz, maximum input
current: 12.0-8.0 Amps
NOTE: For 1200 W power supply, output 1200 W is for
high line (input 200-240 VAC), output 1023 W is for low
line (input 100-120 VAC).
Heat dissipation
4016.251 BTU/hr maximum
Maximum inrush current Initial In-rush Current cannot exceed 55
Amps (peak). Secondary In-rush Current
cannot exceed 35 Amps (peak).
