10 Getting Started With Your System
Connectors
Back
NIC
Two RJ-45 (for integrated 1-GB NICs)
Serial
9-pin, DTE, 16550-compatible
USB
Two 4-pin, USB 2.0-compliant
Video
15-pin VGA
Front
Video
15-pin VGA
USB
Two 4-pin, USB 2.0-compliant
Internal
USB
Two 4-pin, USB 2.0-compliant
Video
Video type Matrox G200, integrated in BMC
Video memory 8 MB graphics memory
Power
AC power supply (per power supply)
Wattag e
350 W (non-redundant power supply)
400 W (redundant power supply)
Voltage
100–240 VAC, 50/60 Hz
Heat dissipation
1571 BTU/hr maximum (non-redundant
power supply)
1666 BTU/hr maximum (redundant
power supply)
Maximum inrush current
Under typical line conditions and over the entire
system ambient operating range, the inrush
current may reach 25 A per power supply for
10 ms or less.
Batteries
System battery
CR 2032 3.0-V lithium coin cell
