Chapter 3 - Installation
5. If necessary, refer to the section Install air duct baffles and blank panel front covers in cabinet.
ATTENTION
Any unused rack mount space must have an air duct baffle and blank front panel
installed.
6. To complete the installation, turn on the server.
3.4.4 Install air duct baffles and blank panel front covers in cabinet
Air duct baffles and blank panel front covers ensure that the airflow within the cabinet allows proper
cooling for the servers. The following image illustrates the air duct baffles and blank panel front covers
used in cabinet.
Figure 3.1 Air Duct Baffle and Blank Panel Front Cover
