No. Task Reference Avaya recommendation
• R610 SRVR 300GB 10K
SAS 2.5” HDD
• R610 SRVR 600GB 10K
SAS 2.5" HDD
• R610 SRVR AC PWR
SUP 502W ES
• R610 SRVR AC PWR
SUP 717W
HOM: Power supplies
Ensure that the replacement
power supply matches the
specifications of the
defective power supply.
4 Slide the server into the rack
(if necessary)
RI-SR Ensure that the Cable
Management Arm (if
present) moves freely out of
the way of rear panel
components.
5 Connect the power cable(s)
to the power supply (if
necessary)
GS: Connecting the Power
Cables
GS: Securing the Power Cord
6 Power up the server (if
necessary)
GS: Turning on the System
Replacing internal components
Use the checklist below to replace any of these internal server components:
Part number
Description
700501323 R610 SRVR DUAL PORT 1GB NIC
700501422 R610 SRVR DVD-RW DRIVE W/ BRKT
700501423 R610 SRVR FAN FRU
700501320 R610 SRVR 2GB MEMORY DIMM
700501320 R610 SRVR 4GB MEMORY DIMM
700501325 R610 SRVR RAID BATTERY
Note:
Although not used frequently, Avaya customers are required to have a monitor, keyboard, and
mouse available for use by installation and/or servicing technicians.
No. Task Reference Avaya
recommendation
1 Have the proper tools HOM: Recommended Tools
Table continues…
